Four-wheel truck 1.6 - 3.0t

3000 - 6500 mm
1600 - 3000 kg

High residual capacity up to 5m
High throughput thanks to the great controller
Fully enclosed AC dual motors with ZF gearbox minimize turning radius while reducing maintenance cost
Precise hydraulic control
Compact lift mast with extended field of vision provides best all-round visibility

EFG MC 316k/ 316/ 320/ 325k/ 325/ 330

The robust and efficient MC series electric four-wheel forklifts offer the ideal combination of stability and maneuverability. The high-pivot steering axle distributes the weight evenly across all four wheels and also absorbs rough road bumps. Thus, you benefit from maximum stability and driving safety, also on uneven ground. An excellent view of the load thanks to the compact lift mast, various assistance systems and equipment options make our EFG trucks reliable and safe helpers in your daily warehouse operations – for efficient goods throughput in any situation. Moreover, the high-resolution, contrast-rich full-color TFT display allows relaxed and fatigue-free working.

Benefits

Connected Trucks

Use the data from your trucks to save time, energy and money and increase efficiency. Our Telematics box (ex factory) provides you with a free fleet management starter package that can be flexibly expanded with various hardware and software components.

Features

Performance

High output AC dual-drive motors and hydraulic motors deliver outstanding power.
Jungheinrich's unique electric-hydraulic system provides state-of-the-art fast, precise and smooth hydraulic controls.
The rigid mast profile and low-gravity truck design provide a high residual capacity.

Maintenance-free electric motors

High torque for rapid work cycles.
Up to 30% greater energy efficiency than with DC motors.
Fully enclosed and protected up to IP54. Long life, even in dusty and damp conditions.
Proven AC technology: dual drive motor, hydraulic pump motor.
High performance, low energy consumption, less maintenance.

Highly efficient lithium-ion battery

Produced by Jungheinrich, safe and reliable.
Integrated battery management system.
High-performance batteries, long life span.
Can completely replace lead-acid batteries.
With counterweight, no additional assembly weight required.
Maintenance-free, easy to charge and use, high efficiency.

Active safety

curveCONTROL automatically reduces travel speed when cornering.
Deactivation of the hydraulic functions when seat is unoccupied.
EasyAccess for authorised users only, either with PIN code or transponder card.
Electronic and hydraulic overload protection guard.
Emergency disconnect switch easily accessible.
Reliable data transfer between electronic components using CAN bus technology.
The whole truck has the IPX5 protection.
Excellent drive dynamics and performance also demand a high degree of safety.

Additional safety features

Strobe light on the overhead guard.
Red or blue spotlight to warn pedestrians in the nearby area.
accessCONTROL: Access control system only allows driving and hydraulic operation when the safety belt is locked.
driveCONTROL: Speed control, which automatically reduces the speed from a defined lift height.
Wet disc brake: maintenance-free disc service brake immersed in oil provides low service cost benefits and significantly improves the reliability of the braking system.
For the operator, truck and load, due to a range of optional operator assistance systems.

Superior operator comfort

Precise hydraulic power steering which requires the minimal amount of effort without kickback.
Comfortable, fatigue-free operation of direction and hydraulics with soloPILOT.
High-resolution TFT 2” display (4” as an option) provides up-to-date information on vital truck conditions at a glance.
Adjustable steering column and comfort seat for optimum seating position. Convenient storage for documents and the operator’s belongings. Moveable armrest available as an option.
Clear view: mast and fork carriage allow for excellent visibility of the load and of the route ahead. LED working light gives best view in dark areas.
The functionality and ergonomics of the operator environment guarantee relaxed and fatigue-free work during long shifts.

Main options

accessCONTROL & EasyAccess PinCode / Transponder
drive&liftPLUS options package
multiPILOT & duoPILOT with double pedal; full suspension seat with adjustable armrest
USB charging interface
Spotlight in red / blue; 4” TFT display
Cold store version (-28℃) & tropics version (up to 50℃)
Lead acid battery capacity 48 V / 500 - 750 Ah; lithium-ion battery capacity 48 V / 390 Ah; spacer and T-parking station (for easy lateral battery exchange)

Model Overview

Model	Load capacity	Lift height	Travel speed	Overall length	Battery voltage
EFG MC 316k	1,600 kg	6,500 mm	19 km/h	2,988 mm	48 V
EFG MC 316	1,600 kg	6,500 mm	19 km/h	3,096 mm	48 V
EFG MC 320	2,000 kg	6,500 mm	19 km/h	3,096 mm	48 V
EFG MC 325k	2,500 kg	5,000 mm	18 km/h	3,213 mm	48 V
EFG MC 325	2,500 kg	5,000 mm	18 km/h	3,321 mm	48 V
EFG MC 330	3,000 kg	5,000 mm	18 km/h	3,469 mm	48 V

Downloads

Product advantages EFG MC pdf (2.5 MB)

Technical data EFG MC pdf (2.2 MB)
