Automated pallet truck

125 mm
2500 kg

Compact design for narrow aisle widths.
Efficient, reliable completion of routine tasks.
Precise pallet handling and optimised transport routes thanks to precise laser navigation.
Extensive safety systems for use in mixed operations.
Short amortisation period thanks to process optimisation.

ERE 225a

As an Automated Guided Vehicle (AGV), our reliable and versatile EREa takes on repetitive transport tasks. With its long forks, the EREa is designed for multi-pallet transport and is therefore the perfect choice for increasing the efficiency of your transport processes. A 2.8-kW 3-phase AC motor ensures constant performance over long distances. Safety is enhanced by the sturdy construction with its steel frame and enclosed structure. The use of our Automated Guided Vehicles in mixed operation is guaranteed by safety systems such as the standard personal protection scanners. Depending on the speed, these scanners scan the travel route for obstacles in the drive direction and when cornering. The truck navigates by means of laser navigation. Reflectors on the travel route or a combination of reflectors and environmental features can be used for this purpose. The AGV developed from our standard trucks can not only be easily integrated into existing IT structures or used as a stand-alone system, but can also be used in existing factory structures or new builds.

Li-Ion

No worries. No compromise.

With the Jungheinrich Li-ion Guarantee Plus, we give you a long-term performance promise of up to 5 years on our high-quality lithium-ion batteries, so you can completely concentrate on your tasks without worrying.

Learn more

100 % satisfaction. Guaranteed.

We are convinced this decision is right for you. That‘s why we guarantee that you can easily and quickly switch back to the original technology at any time within the first 6 months – without stating reasons.

Learn more

Features

Established standard truck used as basis

The basic ERE electric pedestrian pallet truck in combination with comprehensive safety technology as well as automation and navigation components.
Future-proof investment through design of safety equipment in accordance with current standards.
Simple manual operation in mixed mode is performed via the standard controls of the production truck.

Efficient drive technology and equipment

2.8-kW 3-phase AC drive motor.
Capacity up to 2,500 kg.
Sturdy design with steel frame and enclosed frame contours.

Lithium-ion technology

High availability thanks to extremely short charging times.
The use of automated charging means no battery exchange is required.
Cost savings due to longer service life and zero maintenance when compared to lead-acid batteries.
No charging rooms and ventilation required as there is no build-up of gas.

Safety system in the truck

Depending on the speed, the standard personal protection scanner in the drive direction scans the travel route in front of the AGV for obstacles.
Should an obstacle be located in the path of the truck, the AGV will reliably come to a halt in front of it.
The sensor also scans ahead for obstacles when cornering.
Emergency disconnect on the truck.

Process reliability in the warehouse

Everything at a glance with the AGV control panel.
The graphic display on the AGV control panel displays all the information relating to the AGV in use.
Quick overview of the status of pending transport tasks.
Prioritised orders can be entered and processed in the corresponding order.
Depending on the project-specific requirements, individual customer functions can be specially implemented and activated for the respective system.

Simple system integration

Integration into existing IT and network landscapes possible.
Effortless connection to existing WMS / ERP system via Jungheinrich Logistics Interface.
The existing Wi-Fi structure can be used for communication.

Precise navigation
