Automatic tow tractor

5000 kg

Efficient, process-reliable completion of transport tasks
Optimised transport routes thanks to precise laser navigation
Extensive safety systems for use in mixed operations
Various couplings possible
Easy integration into existing IT systems

EZS 350a

Our versatile and robust EZS 350a enhances your production environment as an automated tow tractor. It is particularly suited for the effective pulling of trailers carrying up to 5,000 kg, for example for production supply. The Automated Guided Vehicle System (AGV_S) was developed based on our proven standard trucks in order to specifically optimise warehouse work and transport processes. The automatic tow tractor fulfils routine tasks reliably and convinces with precision navigation technology and an extensive safety system. A 24-V 3-phase AC motor ensures high performance with low energy consumption. The truck is controlled by laser navigation using reflectors installed along the travel route. The EZS 350a can be used in mixed operations mode with manual trucks and pedestrians, in existing structures or as a stand-alone solution – for more efficiency in your production facility.

Li-Ion

No worries. No compromise.

With the Jungheinrich Li-ion Guarantee Plus, we give you a long-term performance promise of up to 5 years on our high-quality lithium-ion batteries, so you can completely concentrate on your tasks without worrying.

Learn more

100 % satisfaction. Guaranteed.

We are convinced this decision is right for you. That‘s why we guarantee that you can easily and quickly switch back to the original technology at any time within the first 6 months – without stating reasons.

Learn more

Features

Established standard truck used as basis

Standard truck EZS 350XL electric tow tractor combined with appropriate safety technology as well as automation and navigation components.
Simple manual operation in mixed mode is performed via the standard controls of the production truck.

Efficient drive technology and equipment

24-V 3-phase AC drive motor.
No carbon brushes: Maintenance-free drive motor.
Robust design.
Compact design.
jetPILOT multifunctional steering wheel.

Lithium-Ionen-Technology

High availability thanks to extremely short charging times.
No battery exchange required.
Saving costs due to longer service life and zero maintenance as compared to lead-acid batteries.
No charging rooms and ventilation required as there is no build-up of gas.

Safety system on the vehicle

Standard personal protection scanner in the drive direction scans the travel route in front of the AGV for obstacles depending on the speed.
Should an obstacle be located in the path of the truck, the AGV will reliably come to a halt in front of it.
The sensor also scans ahead for obstacles when cornering.
Side sensors to protect the sides of the truck.
Emergency disconnect on the truck.

Process reliability in the warehouse

Everything at a glance with the AGV control panel
The graphic display on the AGV control panel displays all the information relating to the AGV in use.
Quick overview of the status of pending transport tasks.
Prioritised orders can be entered and processed in the corresponding order.
Depending on the project-specific requirements, individual customer functions can be specially implemented and activated for the respective system.

Simple system integration

Can be easily integrated into existing IT and network landscapes.
Effortless connection to existing WMS/ERP system via Jungheinrich Logistics Interface.
For communication, the existing Wi-Fi structure is used.

High level of flexibility

Full manual and automatic use, e.g. reliable surface transport in automatic mode with distribution of the goods by one employee.
The optional comfort terminal enables employees to determine the next destination and simply enter it with just one click at the truck.

Precise navigation
